Descrizione prodotto
| Shipping carton height | 62.6 cm |
| Width of shipping carton | 37.4 cm |
| Length of shipping carton | 46.8 cm |
| Net weight of shipping carton | 19.5kg |
| Quantity of shipping carton | 3 pcs |
| Pallet gross weight (air) | 399.8kg |
| Number of cartons per pallet (air) | 18 pcs |
| Quantity per pallet (air) | 54 pcs |
| Pallet length | 110cm |
| Pallet width | 120cm |
| Pallet height (air) | 2.01 m |
| Pallet gross weight (sea) | 399.8kg |
| Number of cartons per pallet (sea) | 18 pcs |
| Quantity per pallet (sea) | 54 pcs |
| Pallet height (sea) | 2.01 m |
| Shipping carton weight | 21.2kg |
| RJ-45 ports quantity | 24 |
| Port type RJ-45 | Gigabit Ethernet (10/100/1000) |
| Quantity of SFP+ module slots | 4 |
| Fiber optic connector | SFP+ |
| USB 2.0 port quantity | 1 |
| Power connector | AC input jack |
| Length | 440 mm |
| Depth | 350 mm |
| Height | 44 mm |
| Weight | 4.66kg |
| Redundant power supply (RPS) support | Yes |
| AC input voltage | 100 - 240V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (max) | 471.67W |
| Operating temperature range | 0 - 50°C |
| Temperature range | -40 - 70°C |
| Operating humidity range | 10 - 90% |
| Humidity | 5 - 90% |
| Heat dissipation | 1609.41 BTU/h |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| Virtual Router Redundancy Protocol (VRRP) | Yes |
| Routing protocol | REP |
| Network standards | IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1s,IEEE 802.1v,IEEE 802.1w,IEEE 802.1x,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3ah,IEEE 802.3at,IEEE 802.3az,IEEE 8 02.3 x |
| Support 10G | Yes |
| Ethernet technology over copper cables | 10BASE-T,10GBASE-T,100BASE-TX,1000BASE-T |
| Door mirroring | Yes |
| Flow control support | Yes |
| Link grouping | Yes |
| Broadcast storm control | Yes |
| Opening protocol tree | Yes |
| Head-of-line (HOL) blocking | Yes |
| VLAN supported | Yes |
| Virtual LAN characteristics | Private VLAN, Voice VLAN, Tagged VLAN, MAC address-based VLAN, Port-based VLAN |
| VLA number | 4000 |
| MAC table dimensions | 16384 entries |
| Switching capability | 168 Gbit/s |
| forwarding rate | 125Mpps |
| Number of queues | 8 |
| Jumbo Frames support | Yes |
| Packet memory buffer | 2MB |
| Packaging width | 450 mm |
| Packaging depth | 595 mm |
| Packaging height | 118mm |
| Packaging weight | 6.32kg |
| DHCP features | DHCP server,DHCP snooping,DHCP relay,DHCP client |
| Access Control List (ACL) | Yes |
| Access Control List (ACL) output | 512 |
| Access Control List (ACL) entry | 2048 |
| IGMP snooping function | Yes |
| Supported security algorithms | SNMP,SNMPv3,SSH-2,SSL/TLS |
| SSH/SSL support | Yes |
| Loop back protection | Yes |
| BPDU Protection/Filter | Yes |
| Authentication | Guest VLAN, MAC-based Authentication, Port-based Authentication |
| Root protection | Yes |
| Password protection | Yes |
| DoS attack prevention | Yes |
| Queue scheduling algorithms | SP, WRR+SP, Weighted Round Robin (WRR) |
| Switch type | Managed |
| Switch level | L3 |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| ARP inspection | Yes |
| System event log | Yes |
| MIB support | RFC 1213; RFC 4188; RFC 1157, 2571-2576; RFC 1907; RFC 1757, 2819; RFC 2021; RFC 1398, 1643, 1650, 2358, 2665; RFC 2674 802.1p 2233, 2863 IF MIB; RFC 2618; RFC 2620; RFC 2925; RFC 2674, 4363; RFC 1065 |
| Stackable | Yes |
| Product color | Black, Grey |
| LED indicators | Yes |
| Number of fans | 3 fan(s) |
| Safety | CB, cUL, BSMI, CCC |
| Certification | FCC A, CE A, VCCI A, IC, RCM, BSMI, CCC |
| Power over Ethernet (PoE) support | Yes |
| Power over Ethernet plus (PoE+) ports quantity | 24 |
| Total PoE power balance | 370W |
| Physical stacking (units) | 9 |
| Virtual Stacking (Unit) | 32 |
| Acoustic emission | 53.4 dB |
| Telnet | Yes |
| sFlow | Yes |
| Mean Time Between Failures (MTBF) | 409054 h |
| Multicast support | Yes |
| Multicast functions | Controllable multicast |
N.B.: Questa scheda è da ritenersi puramente informativa e non contiene alcun tipo di garanzia né implicita né esplicita.
